5.1.2 Interface description
5.1.2.1 Overview
DRIVE-CLiQ interfaces
PE conductor connection
M4 / 1.8 Nm
Shield connection
Digital inputs/outputs
(one green status LED per
channel)
Electronics power supply
LED
X501
X500
X520
X521
X522
X524
Figure 5-1 TM15 interface overview
