6.3 Meaning of the LEDs
Table 6-8 Meanings of the LEDs on the Voltage Sensing Module VSM10
LED Color Status Description, cause Remedy
READY – Off The electronics power supply is missing or outside the per‐
missible tolerance range.
–
Green Continu‐
ous light
The component is ready for operation. Cyclic DRIVE-CLiQ
communication is taking place.
–
Orange Continu‐
ous light
DRIVE-CLiQ communication is being established. –
Red Continu‐
ous light
This component has at least one fault.
Note:
LED is controlled irrespective of the corresponding messages
being reconfigured.
Remove and acknowl‐
edge the fault.
Green/red Flashing
light 0.5
Hz
Firmware is being downloaded. –
Flashing
light 2 Hz
Firmware download has been completed. The system waits
for POWER ON.
Carry out a POWER
ON.
Green/
orange
or
Red/
orange
Flashing
light
Component recognition via LED is activated
1)
.
Note:
Both options depend on the LED status when component rec‐
ognition is activated.
–
1)
See List Manual for the parameter to activate the recognition of components via LED
