5.3 Terminal Module TM150
5.3.1 Description
The terminal module TM150 is a DRIVE-CLiQ component for temperature evaluation. The
temperature is measured in a temperature range from -99 °C to +250 °C for the following
temperature sensors:
● Pt100 (with monitoring for wire break and short-circuit)
● Pt1000 (with monitoring for wire breakage and short-circuit)
● KTY84 (with monitoring for wire breakage and short-circuit)
● PTC (with short-circuit monitoring)
● Bimetallic NC contact (without monitoring)
For the temperature sensor inputs, for each terminal block the evaluation can be parameterized
for 1x2-wire,
2x2-wire, 3-wire or 4-wire. There is no galvanic isolation in the TM150.
The TM150 is mounted in the control cabinet and can be snapped on to a standard mounting
rail (EN 60715).
The TM150 contains the following interfaces:
Table 5-22 Overview of the TM150 interfaces
Type Quantity
DRIVE-CLiQ interfaces 2
Temperature sensor inputs 12
Electronics power supply 1
Terminal Modules
5.3 Terminal Module TM150
Supplementary component descriptions
72 Manual, 06/2019
