Siemens SINUMERIK 810D Programming Guide

3
File and Program Management 08.97
3.4 Definin
g
user data
3
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di
Siemens AG 2000. All rights reserved
3-134
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
4. Activating definition files
•
Up to
SW4
The definition file only becomes active after
the
_N_INITIAL_INI
file is read in.
•
SW 5
and higher
When the GUD definition file is loaded into the
NC ("Load" softkey), it becomes active.
Save all programs, frames and machine data before
reading in
_N_INITIAL_INI
because the static
memory will be formatted.
5. Data storage
When the file
_N_COMPLETE_GUD
is archived
from the working memory, only the data
contained in the file are saved. The definition files
created for the global user variables must be
archived separately.
The variable assignments to global user data are
also stored in
_N_INITIAL_INI
,
the names
must be identical with the names in the definition
files.
Example of a definition file for global data
(machine manufacturer):
%_N_MGUD_DEF
;$PATH=/_N_DEF_DIR
;Global data definitions of the machine manufacturer
DEF NCK SYNRW INT QUANTITY
;Implicit preprocessing stop during read/write
;Spec. data available in the control
;Access from all channels
DEF CHAN INT TOOLTABLE[100]
;Tool table for channel-spec. image
;of the tool number at magazine locations
M30
;Separate table created for each channel
