Siemens SINUMERIK 810D Programming Guide

10
Motion-Synchronous Action 08.97
10.4 Actions within s
y
nchronized actions
10
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
10-384
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
10.4.24 Measurement
Compared with use in traverse blocks of the part
program, the measuring function can be activated
and deactivated as required.
•
Axial measurement without deletion of distance-
to-go:
MEAWA
[axis]=(mode, trigger event_1, ..._4
•
Continuous measurement without deletion of
distance-to-go:
MEAC
[axis]=(mode, measurement memory, trigger event_1, ..._4
For further information on measuring: see Chapter 5, "Extended Measuring Function"
10.4.25 Wait markers set/clear: SETM, CLEARM
Function
SETM(MarkerNumber)
Set wait marker for channel
CLEARM(MarkerNumber)
Clear wait marker for channel
In synchronized actions, wait markers can be set or
deleted for the purpose of coordinating channels, for
example.
SETM
The SETM command can be written in the part
program and in the action part of a synchronized
action. It sets the marker MarkerNumber for the
channel in which the command executes.
CLEARM
The CLEARM command can be written in the part
program and in the action part of a synchronized
action. It resets the flag MarkerNumber for the
channel in which the command executes.
