15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-572
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$AA_EG_SYN
REAL $AA_EG_SYN[a,b]
a: Following axis
b: Leading axis
Synchronized position of leading axis b
Axes: Geometry axis, channel axis, machine axis
RS R 5
.
2
$AA_EG_ACTIVE
BOOL $AA_EG_ACTIVE[a,b]
a: Following axis
b: Leading axis
Coupling for leading axis b is active, i.e. switched on
Axes: Geometry axis, channel axis, machine axis
RS R 5
.
2
15.2.55 Safety Integrated 2
$A_INSE
BOOL $A_INSE[n]
Image of a safety input signal (ext. NCI interface)
n: Number of input 1 – ...
RS R 4
$A_INSED
INT $A_INSED[n]
Image of a safety input signal (ext NCI interface)
n: Number of input word 1 – ...
RS R 5
$A_INSEP
BOOL $A_INSEP[n]
Image of a safety input signal (ext. PLC interface)
n: Number of input 1 – ...
RS R 4
$A_INSEPD
INT $A_INSEPD[n]
Image of a safety input signal (ext PLC interface)
n: Number of input word 0 – ...
RS R 5
$A_OUTSE
BOOL $A_OUTSE[n]
Image of a safety input signal (ext NCI interface)
n: Number of output 1 – ...
RS W
S
RW 4
$A_OUTSED
INT $A_OUTSED[n]
Image of a safety input signal (ext NCI interface)
n: Number of output word 1 – ...
RS W
S
RW 5
$A_OUTSEP
BOOL $A_OUTSEP[n]
Image of a safety input signal (ext PLC interface)
n: Number of output 1 – ...
RS R 4
$A_OUTSEPD
INT $A_OUTSEPD[n]
Image of a safety input signal (ext PLC interface)
n: Number of output word 0 – ...
RS R 5
$A_INSI
BOOL $A_INSI[n]
Image of a safety input signal (int. NCI interface)
n: Number of input 1 – ...
RS R 4
$A_INSID
INT $A_INSID[n]
Image of the safety input signals (int. NCI interface)
n: Number of input word 1 – ...
RS R 5
