04.00 Tables

15.2 List of s

stem variables



SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition

15-557

15.2.35 Polynomial values for synchronized actions

Identifier Type Description: System variable/value range/index Part pro Sync O S

$AC_FCT1LL

REAL $AC_FCT1LL

Lower limit value for evaluation function FCTDEF 1

RS W

RW+ 2

$AC_FCT2LL

REAL $AC_FCT2LL

Lower limit value for evaluation function FCTDEF 2

RS W

RW+ 2

$AC_FCT3LL

REAL $AC_FCT3LL

Lower limit value for evaluation function FCTDEF 3

RS W

RW+ 2

$AC_FCT1UL

REAL $AC_FCT1UL

Upper limit value for evaluation function FCTDEF 1

RS W

RW+ 2

$AC_FCT2UL

REAL $AC_FCT2UL

Upper limit value for evaluation function FCTDEF 2

RS W

RW+ 2

$AC_FCT3UL

REAL $AC_FCT3UL

Upper limit value for evaluation function FCTDEF 3

RS W

RW+ 2

$AC_FCT1C

REAL $AC_FCT1C[n]

Polynomial coefficient a0 – a3 for evaluation function FCTDEF 1

n: Degree of coefficient 0 – 3

RS W

RW+ 2

$AC_FCT2C

REAL $AC_FCT2C[n]

Polynomial coefficient a0 – a3 for evaluation function FCTDEF 2

n: Degree of coefficient 0 – 3

RS W

RW+ 2

$AC_FCT3C

REAL $AC_FCT3C[n]

Polynomial coefficient a0 – a3 for evaluation function FCTDEF 3

n: Degree of coefficient 0 – 3

RS W

RW+ 2

$AC_FCTLL

REAL $AC_FCTLL[n]

Lower limit of polynomial for synchronized actions (SYNFCT)
