SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15.2.6 Monitoring data for tool management
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_MOP1
REAL $TC_MOP1[t,d]
Prewarning limit for tool life
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOP2
REAL $TC_MOP2[t,d]
Remaining tool life
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOP3
INT $TC_MOP3[t,d]
Prewarning limit for number of workpieces
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOP4
INT $TC_MOP4[t,d]
Remaining number of workpieces
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_MOP5
REAL $TC_MOP5[t,d]
Prewarning limit wear
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_MOP6
REAL $TC_MOP6[t,d]
Remaining wear
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_MOP11
REAL $TC_MOP11[t,d]
Service life setpoint
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_MOP13
INT $TC_MOP13[t,d]
Workpiece count setpoint
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_MOP15
REAL $TC_MOP15[t,d]
Wear setpoint
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
