04.00 Tool Offsets
8.1 Offset memor
y
8
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
8-265
Tool parameters
number (DP)
Meaning Comment
$TC_DP 1
Tool type For overview see list
$TC_DP 2
Tool point direction For turning tools only
Geometry Tool length compensation
$TC_DP 3
Length 1 Calculation depending
$TC_DP 4
Length 2 on type and plane
$TC_DP 5
Length 3
Geometry Radius
$TC_DP 6
Radius
$TC_DP 7
Slot width b for slotting saw, rounding radius
for milling tools
$TC_DP 8
Overhang k For slotting saw only
$TC_DP 11
Angle for cone milling tools
Wear Tool length and radius compensation
$TC_DP 12
Length 1
$TC_DP 13
Length 2
$TC_DP 14
Length 3
$TC_DP 15
Radius
$TC_DP 16
Slot width b for slotting saw, rounding radius
for milling tools
$TC_DP 17
Overhang k For slotting saw only
$TC_DP 20
Angle for cone milling tools
Base dimensions/
adapter
Tool length compensation
$TC_DP 21
Length 1
$TC_DP 22
Length 2
$TC_DP 23
Length 3
Technology
$TC_DP 24
Clearance angle For turning tools
Additional notes
All other parameters are reserved.
Machine manufacturer
User cutting edge data can be configured via MD.
