13
12.98 Additional Functions
13.4 EG: Electronic
g
ear
(
SW 5 and hi
g
her
)
13
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
13-445
13.4.3 Deactivate electronic gear
There are three different ways to deactivate an
active EG axis grouping.
Variant 1:
EGOFS(following axis)
The electronic gear is deactivated. The
following axis is decelerated until it is
motionless.
The call triggers preprocessing stop.
Variant 2:
EGOFS(following axis, leading axis 1,
... leading axis 5)
This command parameter setting make it
possible to
selectively
remove the
control the individual leading axes have
over the following axis' motion.
At least one leading axis must be specified. The
influence of the specified leading axes on the
following axis is selectively disabled.
The call triggers preprocessing stop.
If leading axes are still active, the following axis will
continue to operate under their control. If all leading
axis influences have been disabled in this manner,
the following axis is decelerated until it reaches a
standstill.
Variant 3:
EGOFC(following spindle)
The electronic gear is deactivated. The
following spindle continues to operate
with the current speed that was valid at
the time of deactivation.
The call triggers preprocessing stop.
Note
This functions is only allowed for spindles.
