Siemens SINUMERIK 810D Programming Guide

9
Path Traversing Behavior 08.97
9.7 Re
p
ositionin
g
on contour
,
REPOSA
,
REPOSL
,
REPOSQ
,
REPOSH
9
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
9-332
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
9.7 Repositioning on contour, REPOSA, REPOSL, REPOSQ, REPOSH
Programming
REPOSA RMI DISPR=…
or
REPOSA RMB
or
REPOSA RME
REPOSL RMI DISPR=…
or
REPOSL RMB
or
REPOSL RME
REPOSQ RMI DISPR=… DISR=…
or
REPOSQ RMB DISR=…
or
REPOSQ RME DISR=…
or
REPOSQA DISR=…
REPOSH RMI DISPR=… DISR=…
or
REPOSH RMB DISR=…
or
REPOSH RME DISR=…
or
REPOSHA DISR=…
Explanation of the commands
Approach path
REPOSA
Approach along line on all axes
REPOSL
Approach along line
REPOSQ DISR=…
Approach along quadrant with radius DISR
REPOSQA DISR=…
Approach on all axes along quadrant with radius DISR
REPOSH DISR=…
Approach along semi-circle with diameter DISR
REPOSHA DISR=…
Approach on all axes along semi-circle with diameter DISR
Repositioning point
RMI
Approach interruption point
RMI DISPR=…
Entry point at distance DISPR in mm/inch
in front of
interruption point
RMB
Approach block start point
RME DISPR=…
Approach block end point at distance DISPR in front of end point
A0 B0 C0
Axes in which approach is to be made
