7
08.97 Transformations
7.4 Inclined axis: TRAANG
7
840D
NCU 572
NCU 573
810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
7-247
7.4 Inclined axis: TRAANG
Programming
TRAANG(
α
)
or
TRAANG(
α
,n)
TRAFOOF
Explanation of the commands
TRAANG(
α
)
Activates the first declared inclined
transformation axis
TRAANG(
α
,n)
Activates the nth declared
inclined transformation axis. n may not
exceed 2. TRAANG(
α
,1) corresponds to
TRAANG(
α
).
α
Angle of the inclined axis
TRAFOOF
Transformation off
If
α
(angle) is omitted or a zero entered, the
transformation is activated with the parameter
settings of the previous selection. On the first
selection, the defaults in the machine data are used.
An active TRAANG transformation is also
deactivated if one of the other transformations (e.g.
TRACYL, TRANSMIT, TRAORI) is activated on the
same channel.
