7
Transformations 08.97
7.4 Inclined axis: TRAANG
7
840 D
NCU 572
NCU 573
810D
840Di
ï›™
Siemens AG 2000. All rights reserved
7-248
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
Function
The inclined axis function is intended for grinding
and provides the following capabilities:
•
Machining with inclined infeed axis
•
A Cartesian coordinate system can be used for
programming.
•
The control transforms the programmed
traversing movements of the Cartesian
coordinate system into traversing movements on
the real machine axes (standard setting): inclined
infeed axis.
MU
AS
MZ
C
Z
X
Workpiece
Grinding
wheel
α
The following machining operations are possible:
1. Longitudinal grinding
2. Transverse grinding
3. Grinding of a specific contour
4. Inclined recess grinding
1
3
2
4
