15
04.00 Tables
15.2 List of s
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-513
15.2.4 Channel-specific protection zones
Identifier Type Description: System variable/value range/index Part pro Sync O S
$SC_PA_ACTIV_I
MMED
BOOL $SC_PA_ACTIV_IMMED[n]
Protection zone active immediately?
TRUE: The protection zone is active immediately upon start-up of the
control and referencing of the axes
FALSE: The protection zone is not active immediately
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_T_W
CHAR $SC_PA_T_W[n]
Workpiece/tool-oriented prot. zone
0: Workpiece-oriented protection zone
3: Tool-oriented protection zone
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_ORI
INT $SC_PA_ORI[n]
Orientation of protection zone
0: Polygon in plane from 1st and 2nd geo axis
1: Polygon in plane from 3rd and 1st geo axis
2: Polygon in plane from 2nd and 3rd geo axis
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_LIM_3DI
M
INT $SC_PA_LIM_3DIM[n]
Code for restricting the protection zone in the axis that lies parallel to
the polygon definition
0: = No limit
1: = Limit in positive direction
2: = Limit in negative direction
3: = Limit in both directions
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_PLUS_L
IM
REAL $SC_PA_PLUS_LIM[n]
Positive limit for the protection zone in the axis that lies perpendicular
to the polygon definition
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_MINUS_
LIM
REAL $SC_PA_MINUS_LIM[n]
Negative limit for prot. zone in minus direction that lies perpendicular
to polygon definition
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
$SC_PA_CONT_
NUM
INT $SC_PA_CONT_NUM[n]
Number of valid contour elements
n: Number of protection zone 0 – (maximum value settable via MD)
RW 2
