15
04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-533
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_MAP5
INT $TC_MAP5[n]
Chaining with previous magazine
n: Magazine number 1 to ...
RW 2
$TC_MAP6
INT $TC_MAP6[n]
Number of rows
n: Magazine number 1 to ...
RW 2
$TC_MAP7
INT $TC_MAP7[n]
Number of columns
n: Magazine number 1 to ...
RW 2
$TC_MAP8
INT $TC_MAP8[n]
Current magazine position with reference to the change position
n: Magazine number 1 to ...
RW 2
$TC_MAP9
INT $TC_MAP9[n]
Current wear group number
n: Magazine number 1 to ...
RW 5
15.2.13 Tool management magazine description data for OEM users
$TC_MAPC1
INT The type can be defined in the machine data. The default is INT
$TC_MAPC1[n]
n: Magazine number 1 to ...
RW 2
$TC_MAPC2
INT The type can be defined in the machine data. The default is INT
$TC_MAPC2[n]
n: Magazine number 1 to ...
RW 2
...
... ...
$TC_MAPC10
INT The type can be defined in the machine data. The default is INT
$TC_MAPC10[n]
n: Magazine number 1 to ...
RW 2
$TC_MAPCS1
INT The type can be defined in the machine data. The default is INT
$TC_MAPCS1[n]
n: Magazine number 1 to ...
RW 5
.
2
$TC_MAPCS2
INT The type can be defined in the machine data. The default is INT
$TC_MAPCS2[n]
n: Magazine number 1 to ...
RW 5
.
2
...
... ...
$TC_MAPCS10
INT The type can be defined in the machine data. The default is INT
$TC_MAPCS10[n]
n: Magazine number 1 to ...
RW 5
.
2
