13
Additional Functions 12.98
13.4 EG: Electronic
g
ear
(
SW 5 and hi
g
her
)
13
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
13-446
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
13.4.4 Delete definition of an electronic gear
An EG axis grouping must be deactivated as
described in the preceding section before you can
delete its definition.
EGDEL(following axis)
The coupling definition of the axis
grouping is deleted.
Additional axis groupings can be defined
by means of EGDEF until the maximum
number of simultaneously activated axis
groupings is reached.
The call triggers preprocessing stop.
13.4.5 Revolutional feedrate (G95)/electronic gear (SW 5.2)
In SW 5 and higher, using the FPR() command, it is
also possible to define the following axis of an
electronic gear as the axis determining the
revolutional feedrate. The following applies in this
case:
•
The feed is dependent on the setpoint speed of
the following axis of the electronic gear.
•
The setpoint speed is calculated from the speed
of the leading spindles and modulo leading axes
(that are not path axes) and their assigned
coupling factors.
•
Speed parts of linear or non-modulo leading axes
and overlaid movement of the following axis are
not taken into account.
