13
12.98 Additional Functions
13.3 S
y
nchronized s
p
indle
13
840D
NCU 571
840D
NCU 572
NCU 573
840Di
ï›™
Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
13-431
13.3 Synchronized spindle
Programming
COUPDEF (FS,LS,SR
FS
,SR
LS
, block change beh., coupling)
COUPDEL (FS,LS)
COUPRES (FS,LS)
COUPON (FS,LS,PS
FS
)
COUPOF (FS,LS,POS
FS
,POS
LS
)
WAITC (FS, block change beh., FS, block change beh.)
Explanation of the commands
COUPDEF
Define/change user coupling
COUPON
Activate coupling
COUPOF
Deactivate coupling
COUPRES
Reset coupling parameters
COUPDEL
Delete user-defined coupling
WAITC
Wait for synchronism condition
Explanation of the parameters
FS, LS
Name of following and leading spindle; specified with spindle number:
e.g. S2
SR
FS
, SR
LS
Speed ratio parameter for following spindle and leading spindle
Default setting = 1.0; specification of denominator optional
Block change
behavior:
•
"NOC"
•
"FINE"
•
"COARSE"
•
"IPOSTOP"
Block change method; Block change is implemented by:
Immediate (default)
in response to "Synchronization run fine"
in response to "Synchronization run coarse"
in response to IPOSTOP (i.e. after setpoint synchronization run)
Coupling
•
"DV"
•
"AV"
Coupling type: Coupling between FS and LS
Setpoint coupling (default)
Actual-value coupling
PS
FS
Angle offset between leading and following spindles
POS
FS
, POS
LS
Deactivation positions of following and leading spindles
