Linking complete frames
A complete frame can be assigned to another frame.
Programming (examples)
DEF FRAME SETTING1
SETTING1=CTRANS(X,10)
$P_PFRAME=SETTING1
DEF FRAME SETTING4
SETTING4=$P_PFRAME
$P_PFRAME=SETTING4
Assign the values of the user frame
SETTING1
to the current programmable
frame.
The current programmable frame is
stored temporarily and can be recalled.
Additional notes
Value range for RT rotation
Rotation around 1st geometry axis: –180° to +180°
Rotation around 2nd geometry axis: –89.999° to +90°
Rotation around 3rd geometry axis: –180° to +180°
Frame chaining
Programming (examples)
$P_IFRAME=$P_UIFR[15]:$P_UIFR[16]
$P_UIFR[3]=$P_UIFR[4]:$P_UIFR[5]
$P_UIFR[15
] contains, for example,
data for zero offsets. The data of
$P_UIFR[16]
, e.g. data for rotations,
are subsequently processed additively.
The settable frame 3 is created by
chaining the settable frames 4 and 5.
