7
Transformations 08.97
7.7 Chained transformations
7
840 D
NCU 572
NCU 573
810D 840Di

Siemens AG 2000. All rights reserved
7-256
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
par
One or several parameters separated by
commas for the transformation in the
chain, the parameters require input of, for
example, the angle of the inclined axis.
If the parameters are not set, the default
settings or the parameters that were last
used are effective. Commas must be
inserted to ensure that the specified
parameters are evaluated in the
sequence in which they are required if
default settings are to be effective for
preceding parameters. In particular,
when specifying at least one parameter, it
must be preceded by a comma, even if it
is not necessary to specify trf, for
example TRACON( , 3.7).
Function
The chained transformation is activated. Any other
previously activated transformation is implicitly
deactivated with TRACON().
A tool is always assigned to the first transformation
of a chain. The following transformation then
behaves as if the active tool length were zero. Only
the base lengths of a tool (_BASE_TOOL_) set in
the machine data are valid for the
first
transformation of the chain.
Deactivation
Programming
TRAFOOF
Function
The command deactivates the (chained)
transformation that was last activated.
