08.97 Motion-Synchronous Action
10.7 Su
pp
lementar
y
conditions
10
840D
NCU 571
840D
NCU 572
NCU 573
FM-NC 810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
10-393
Response following end of program
Synchronized action /
technology cycle
Modal and non-modal
are reset
Static (IDS)
remain active
Axis /
positioning spindle
M30 is delayed until the axis/spindle is
stationary.
Movement continues
Speed-controlled spindle
End of program:
$MA_SPIND_ACTIVE_AFTER_RESET==1:
Spindle remains active
$MA_SPIND_ACTIVE_AFTER_RESET==0:
Spindle is stopped
Spindle remains active following a change in
operating mode
Spindle remains active
Leading value coupling
$MC_RESET_MODE_MASK, Bit13 == 1:
Leading value coupling remains active
$MC_RESET_MODE_MASK, Bit13 == 0:
Leading value coupling is disconnected
A coupling started from a static
synchronized action remains
Measuring procedures
Measurements started from synchronized
actions are cancelled.
Measurements started from
static synchronized actions
remain active.
•
Block search
Synchronized actions found during a block
search Block searchare collected and evaluated
on NC Start; the associated actions are then
started if necessary.
Static synchronized actions are active during
block search.
If polynomial coefficients programmed with
FCTDEF are found during a block search, they
are written directly to the setting data.
•
Program interruption by asynchronized
subroutine
ASUP start:
Modal and static motion-synchronized actions
remain active and are also active in the
asynchronized subroutine.
