15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-540
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$P_TOOLL
REAL $P_TOOLL[n]
Active total tool length
n: Length 1 – 3
R2
$P_TCANG
REAL $P_TCANG[n]
Active angle of toolholder axis
n: Angle 1 – 2
R5
$P_TOOLR
REAL $P_TOOLR
Active tool radius (total)
R2
$P_TOOLND
INT $P_TOOLND[t]
Number of cutting edges of tool t
t: T number 1 – 32000
R4
$P_TOOLEXIST
BOOL $P_TOOLEXIST[t]
Tool with T No. t exists
t: T number 1 – 32000
R4
$P_D
INT $P_D
Current D number in ISO_2-language mode
R5
.
2
$P_H
INT $P_H
Current H number in ISO_2-language mode
R5
.
2
$A_TOOLMN
INT $A_TOOLMN[t]
Magazine number of tool t
t: T number 1 – 32000
R4
$A_TOOLMLN
INT $A_TOOLMLN[t]
Magazine number of tool t
t: T number 1 – 32000
R4
$A_MONIFACT
REAL $A_MONIFACT
Factor for tool length monitoring
RW
S
RW 4
$AC_MONMIN
REAL $AC_MONMIN
Ratio between tool monitoring actual value and setpoint.
Threshold for tool search strategy "load only tools
with actual value greater than threshold"
RW
S
RW 5
.
2
$P_VDITCP
INT $P_VDITCP[n]
Available parameters for tool management on VDI interface
n: Index 1 – 3
RW 2
$A_DNO
INT $A_DNO[i]
Read a D number defined by the PLC via VDI interface
i: Index 1 – 9 for table location in D number table
R4
$P_ATPG
REAL $P_ATPG[n]
Current tool-related grinding data
n: Parameter number 1 – 9
RW 2
