04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-545
Identifier Type Description: System variable/value range/index Part pro Sync O S
$AC_ASUP
INT $AC_ASUP
Code number for the cause of the ASUP activation. The reasons bit-
coded and have the following meanings:
BIT0:
Activation due to: User interrupt "ASUP with Blsync"
Activation by: VDI signal, digital/analog interface
Continuation by: user-selectable Reorg or Ret
BIT1:
Activation due to: User interrupt "ASUP"
For program continuation with Repos, the position after stopping is
stored.
Activation by: VDI signal, digital/analog interface
Continuation by: user-selectable
BIT2
: Activation due to: User interrupt "ASUP from Ready channel
status"
Activation by: VDI signal, digital/analog interface
Continuation by: user-selectable
BIT3:
Activation due to: User interrupt "ASUP in a manual mode and
Ready channel status"
Activation by: VDI signal, digital/analog interface
Continuation by: user-selectable
BIT4:
Activation due to: User interrupt "ASUP"
For program continuation with Repos, the current position where the
interrupt occurred is stored.
Activation by: VDI signal, digital/analog interface
Continuation by: user-selectable
BIT5:
Activation due to: Cancelation of subprogram repetition
Activation by: VDI signal
Continuation by: using system ASUP REPOS
BIT6:
Activation due to: Activation of decoding single block
Activation by: VDI signal (+OPI)
Continuation by: using system ASUP REPOS
BIT7:
Activation due to: Activation of delete distance to go
Activation by: VDI signal
Continuation by: using system ASUP Ret
BIT8:
Activation due to: Activation of axis synchronization
Activation by: VDI signal
Continuation by: using system ASUP REPOS
BIT9:
Activation due to: Mode change
Activation by: VDI signal
Continuation by: using system ASUP REPOS or RET (see MD.)
BIT10:
Activation due to: Program continuation with teach-in or after
teach-in deactivation
Activation by: VDI signal
Continuation by: using system ASUP Ret
BIT11:
Activation due to: Overstore selection
Activation by: PI selection
Continuation by: using system ASUP REPOS
BIT12:
Activation due to: Alarm with reaction of compensation block
with Repos (COMPBLOCKWITHREORG)
Activation by: Internal
Continuation by: using system ASUP REPOS
BIT13:
Activation due to: Retraction movement on G33 and Stop
RS R 4
