Siemens SIPROTEC 5 Hardware Description

Input and Output Modules of the Non-Modular Devices (7xx82)
Function Description of the Input and Output Modules of the Non-Modular
Devices
Module Designation Function Description
IO101
•
Input and output module
•
4 current measuring inputs, 8 binary inputs, 6 binary outputs
IO102
•
Input and output module
•
4 current measuring inputs, 4 voltage measuring inputs, 8 binary inputs,
6 binary outputs
IO103
•
Input and output module
•
8 current measuring inputs, 4 binary inputs, 4 binary outputs
IO110
•
Input and output module
•
12 binary inputs, 7 binary outputs
IO111
•
Input module
•
12 temperature inputs
Input and Output Module IO101
Description
The terminals for the following are located on the input and output module IO101:
•
4 current transformers (3 transformers always as protection-class current transformers, the 4th optionally
as protection-class or instrument transformer)
•
8 binary inputs
•
6 binary outputs, of which:
– 4 standard make contacts (type S)
– 2 standard change-over contacts (type S)
The connections are distributed over:
•
1 x 8-pole current terminal
•
2 x 14-pole voltage terminal
3.4
3.4.1
3.4.2
3.4.2.1
Electronic Modules
3.4 Input and Output Modules of the Non-Modular Devices (7xx82)
108 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
