Siemens SIPROTEC 5 Hardware Description

Function Description of Plug-In Modules of Modular and Non-
Modular Devices
Plug-In Module
Designation
Function Description
USART-xx-yEL Serial communication module with electric transmission
USART-xx-yFO Serial communication module with optical transmission for short distance
USART-xx-yLDFO Serial communication module with optical transmission for long distance
ETH-xx-2EL Ethernet module with electric transmission
ETH-xx-2FO Ethernet module with optical transmission
ANAI-CA-4EL Measuring-transducer module
ARC-CD-3FO Module for connecting optical sensors for detecting arcs
xx
y
2 letters, unique code for the module in the product code of the device
1 = 1 channel
2 = 2 channels
4.1
Plug-In Modules
4.1 Function Description of Plug-In Modules of Modular and Non-Modular Devices
128 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
