Measuring-Transducer Modules
Overview
You can install the measuring-transducer modules in base modules or 1/3 modules (plug-in module positions E
and F) and in expansion modules with a CB202 plug-in module assembly (plug-in module position M, N, or P).
ANAI-CA-4EL
The ports CH1 to CH4 of the measuring-transducer modules are Protective Extra Low Voltage circuits (PELV
circuits). For the connection to the measuring-transducer modules, the following conditions apply:
•
PELV circuits may be connected only to PELV circuits.
•
Ensure that the lines of PELV circuits are routed separately from the supply circuits.
•
Use shielded lines.
Product code P1Z1137
Figure
Terminal diagram
Connector type 8-pin terminal spring
Input channels 4 differential current inputs
Measuring range -20 mA DC to +20 mA DC
Tolerance 0.5 % of measuring range
Maximum measuring range -25.6 mA DC to +25.6 mA DC
Input impedance 140 Ω
Permissible potential difference
between channels
DC 20 V
Permissible overload DC 100 mA continuously
4.3
4.3.1
4.3.2
Plug-In Modules
4.3 Measuring-Transducer Modules
180 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-N, Edition 04.2022
