Siemens SIPROTEC 5 Hardware Description

Technical Data
6.1 Analog Inputs 190
6.2 Supply Voltage 193
6.3 Binary Inputs 195
6.4 Relay Outputs 196
6.5 Light-Emitting Diodes in the On-Site Operation Panel 198
6.6 Communication Interfaces 199
6.7 Electrical Tests 202
6.8 Mechanical Tests 205
6.9 Environmental Conditions 206
6.10 Operating Conditions 208
6.11 Reference Conditions and Influencing Variables 209
6.12 Approvals 210
6.13 Design Data 211
6.14 Assembly Dimensions 214
6.15 Modular Device Name Plate 235
6.16 Name Plate of Non-Modular Devices (7xx82) 236
6.17 Name Plate, UL Approval, Base Module and 1/3 Base Module 237
6.18 Name Plate, UL Approval, Expansion Module 238
6.19 Battery 239
6.20 SDHC Memory Card 240
6.21 Display Resolution 241
6
SIPROTEC 5, Hardware Description, Manual 189
C53000-G5040-C002-C, Edition 10.2017
