Siemens SIPROTEC 5 Hardware Description

Input and Output Modules of the Modular Devices
Function Description of the Input and Output Modules of the Modular Devices
Module Designation Function Description
IO201
•
Input and output module
•
4 current measuring inputs, 8 binary inputs, 6 binary outputs
IO202
•
Input and output module
•
4 current measuring inputs, 4 voltage measuring inputs, 8 binary inputs,
6 binary outputs
IO203
•
Input and output module
•
8 current measuring inputs, 4 binary inputs, 4 binary outputs
IO204
•
Input and output module
•
10 binary inputs, 4 binary outputs, 4 power relays for controlling 2 motors
IO205
•
Input and output module
•
12 binary inputs, 16 binary outputs
IO206
•
Input and output module
•
6 binary inputs, 7 binary outputs
IO207
•
Input and output module
•
16 binary inputs, 8 binary outputs
IO208
•
Input and output module
•
4 current measuring inputs, 4 voltage measuring inputs, 4 binary inputs,
11 binary outputs
IO209
•
Input and output module
•
8 binary inputs, 4 high-speed binary outputs (semiconductor accelerated)
IO210
•
Input and output module
•
4 current measuring inputs, 3 voltage measuring inputs, 4 high-speed meas-
uring-transducer inputs for current or voltage, 7 binary outputs
IO211
•
Input and output module
•
8 voltage inputs, 8 binary inputs
IO212
•
Input and output module
•
8 high-speed measuring-transducer inputs for current or voltage, 8 binary
inputs
IO214
•
Input and output module
•
4 current measuring inputs, 4 voltage measuring inputs, 2 binary inputs,
5 binary outputs
IO215
•
Input and output module
•
4 current measuring inputs, 4 voltage measuring inputs (measuring range:
7.07 V), 8 binary inputs, 6 binary outputs
IO230
•
Input module
•
48 binary inputs
IO231
•
Input and output module
•
24 binary inputs
•
24 binary outputs
IO233
•
Input module with special version for binary inputs. You can find more infor-
mation in chapter 6 Technical Data.
•
48 binary inputs
PB201
•
Process-bus module
•
7 duplex LC interfaces of which 1 is a service port
3.2
3.2.1
Electronic Modules
3.2 Input and Output Modules of the Modular Devices
54 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
