Siemens SIPROTEC 5 Hardware Description

Safety Notes
!
DANGER
Danger during electrical inspection
Noncompliance with the safety notes will result in death, severe injury or considerable material
damage.
²
Comply with all given safety notes when carrying out the electrical inspection.
²
Please note that hazardous voltages are present when you perform the electrical inspection.
²
During the electrical inspection, check that the device becomes ready for operation once it has been
connected to the power supply.
Performing the Electrical Inspection
²
Connect the power supply.
²
Activate the power supply.
After (initial) activation, there is no Device Configuration File (CFG) in the device and the device is in fall-
back mode. The green and red LEDs light up in fallback mode.
²
Once you have loaded the CFG file into the SIPROTEC 5 device, the green RUN LED lights up continuously
and the device is ready for operation.
²
If the device does not assume the normal operating state (process mode), switch off the power supply.
Disconnect the wiring and the grounding.
²
Pack this device and return it to the manufacturer, stating the defect. Use transport packaging that meets
the requirements of standard ISO 2248.
Working on the Device
5.1 First Steps
SIPROTEC 5, Hardware Description, Manual 155
C53000-G5040-C002-C, Edition 10.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
