²
Carefully pull out the terminal block.
²
Seal the contacts with a cover cap (see Figure 5-27 and Figure 5-28).
Installation
²
Pull the cover cap off the terminal.
²
Carefully insert the terminal block into the spring clips.
²
Both spring clips must engage clearly audibly.
Working on the Device
5.7 Installing Current and Voltage Terminals
SIPROTEC 5, Hardware Description, Manual 223
C53000-G5040-C002-N, Edition 04.2022
