Design Data
Masses
Device Size
Weight of the Modular Devices
Type of construction 1/3 1/2 2/3 5/6 1/1
Flush-mounting device 4.4 kg 7.2 kg 9.9 kg 12.7 kg 15.5 kg
Surface-mounted device with inte-
grated on-site operation panel
7.4 kg 11.7 kg 15.9 kg 20.2 kg 24.5 kg
Surface-mounted device with
detached on-site operation panel
4.7 kg 7.8 kg 10.8 kg 13.9 kg 17.0 kg
Devices with IO240 weigh 0.9 kg more.
Size Weight
Detached on-site operation panel 1/3 1.9 kg
Detached on-site operation panel 1/6 1.1 kg
Device Size
Weight of the Non-Modular Devices 7xx81, 7xx82
Type of construction 1/3
Flush-mounting device 3.6 kg
Bracket for non-modular surface-
mounting version
1.9 kg
Dimensions of the Base and Expansion Modules
Type of Construction
Max. Total Width x Max. Total Height x
Max. Total Depth
32
, Each Rounded up to
the Next Full mm (in Inches)
Flush-mounting device Base module 150 mm x 266 mm x 231 mm
(5.91 x 10.47 x 9.09)
Base module with IO240 150 mm x 266 mm x 277 mm
(5.91 x 10.47 x 10.91)
Base module with IO111 150 mm x 266 mm x 243 mm
(5.91 x 10.47 x 9.57)
Expansion module 75 mm x 266 mm x 231 mm
(2.95 x 10.47 x 9.09)
Expansion module with IO240 75 mm x 266 mm x 277 mm
(2.95 x 10.47 x 10.91)
Expansion module with IO111 75 mm x 266 mm x 243 mm
(2.95 x 10.47 x 9.57)
Surface-mounted device with
integrated on-site operation
panel
Base module 150 mm x 315 mm x 341 mm
(5.91 x 12.4 x 13.43)
Expansion module 75 mm x 315 mm x 341 mm
(2.95 x 12.4 x 13.43)
6.13
32
Including current terminal, excluding USB port cover
Technical Data
6.13 Design Data
