Information table for function parameters 7SD600
SETT. – parameter block processing
00 PRO – device scope
00 PW.MON
No.AVAI. Configure pilot wire monitoring
AVAIL. [ ] not available
[ ] available
01 SYSTEM DATA – system/line data
01 Sysf rated frequency
50 Hz [ ] fN 50 Hz
60 Hz [ ] fN 60 Hz
01 IN Ln rated current of the line
min. 1 A
max. 100000 ––––
01 IW PRI Primary rated current
of the main CT transformer
min. 1 A
max. 100000 ––––
01 Rx resistance of the pilot wire loop
min. 0 Û
max. 2000 ––––
01 TAUSK minimum duration of the trip command
min 0.01 s
max. 60.00 ––––
01 L.Out status of the Lockout function
OFF [ ] off
ON [ ] on
01 L.O.Fr reset the lockout
KEY [ ] with LED Quit key
BI [ ] via binary input
KEY BI [ ] with key or bin.
10 LINE DIFFPRO. – line differential protection
10 DIFPRO status of the line differential protection
ON [ ] on
OFF [ ] off
IND. ONLY [ ] indication only
10 I–DIF> pick–up threshold of the differential current
min. 050 InL
max. 2.50 ––––
10 I1>Ena min. summation CT current
for enabling the TRIP signal
min. 0.00 InL
max. 1.50 ––––
