10 T DELAY delay time for the trip
min. 0.00 s
max. 60.00 ––––
10 2HARM blocking with 2nd harmonic on/off
OFF [ ] off
ON [ ] on
10 Harm2% 2nd harmon. component in diff.
current for blocking
min. 10 %
max. 80 ––––
10 Harm2I max. diff. current for block. by 2nd harmon.
min. 1.00 InL
max. 10.00 ––––
10 MIT.SE status of the transfer trip function
OFF [ ] off
ON [ ] on
10 M.EXT transfer trip extension time
min. 0.00 s
max. 5.00 ––––
10 I–SpC pick–up threshold for block. by diff. current
min. 0.10 InL
max.1.00/’y ––––
10 T–SpC delay time für block. by diff. current
min. 5 s
max. 60 ––––
11 PILOT WIRE MON – pilot wire monitoring
11 PW.MON status of the pilot wire monitoring
ON [ ] on
OFF [ ] off
11 STATN. station ID for establishing connection
MASTER [ ] Master
SLAVE [ ] Slave
11 DIF.BL block. diff. protection
in case of pilot wire interruption
ON [ ] on
OFF [ ] off
11 T–DiBL delay time for the diff. protection blocking
min. 1 s
max. 60 ––––
12 REMOTE TRIP. – remote tripping
12 S.EXT extension of the remote trip signal
min. 0.00 s
max. 60.00 ––––
