|FNo.|Text |Meaning |Op|Flt|I|O|
++ + ++++|
|3303|>RT blk |>blocking of the remote trip | | |I|O|
|3306|>R–TRIP |>remote trip of the remote station | | |I|O|
|3312|RT blk. |remote trip is blocked |KG| | |O|
|3316|RT send |remote trip is sent |KG| | |O|
|3333|>Rec.bl |>blocking of TRIP by remote station | | |I|O|
|3341|Rec.off |TRIP by remote station is switched off |KG| | |O|
|3342|Rec.blk |TRIP by remote station: blocked |KG| | |O|
|3343|Rec.act |TRIP by remote station: active |KG| | |O|
|3346|Rec.Act |TRIP by remote station: activation | |KG| |O|
|3347|Rec.TRIP |TRIP by remote station: trip | |K | |O|
|3348|Rec.rec |TRIP by remote station: signal received |KG| | |O|
|3363|>PWM bl |>blocking of pilot wire monitoring | | |I|O|
|3371|PWM off |pilot wire monitoring is switched off |KG| | |O|
|3372|PWM blk |pilot wire monitoring blocked |KG| | |O|
|3376|Flt.WM |fault in the pilot wire connection |KG| | |O|
+ +
Indications of the 7SD600 for the LSA
(according to DIN 19244 / according to VDEW/ZVEI)
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
FNo. – function number of the event
Op/Flt – operational/fault event
K/KG: coming/coming and going event
V : event with numerical value
MV : measured value
LSA No.– number of the indication for LSA (acc. to DIN 19244) acc. to VDEW/ZVEI:
CI – compatible indication
GR – indication for general request
MI – mark indication for fault value buffer
Type – function type (p: according to the parameter ”function type”)
Inf – information number
+ +
| | | Type |LSA| VDEW/ZVEI |
|FNo.|Meaning |Op|Flt|No.|CI|GR|MI|Type|Inf|
+ + + + + ++++ + |
| 511|protection (gen.) general tripping | |K |141| | |MI|192|161|
| 605|operational measured value current I1 in % |MV| | | | | |134|130|
|3376|fault in the pilot wire connection |KG| | 95| |GR| |192| 76|
+ +
