Indications of the 7SD600 for PC, LC–display and Binary inputs/outputs
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
FNo. – function number of the event
Op/Flt – operational/fault event
K/KG: coming/coming and going event
MV : measured value
E: marshalled to binary input
A: marshalled to binary output (LED, indication/command relay)
+ +
|FNo.|Text |Meaning |Op|Flt|I|O|
+ + + ++++|
| 1|n.marsh |not marshalled | | |I|O|
| 5|>LED r. |>Reset LEDs | | |I|O|
| 52|Pro act. |at least one protective function is active |KG| | |O|
| 60|LED–RS |Reset LEDs |K | | | |
| 83|SigTest |internally used signaling indication | | | | |
| 110|IndLost |indications lost |K | | | |
| 111|IndPCls |indications for PC lost |K | | | |
| 113|Tag lost |tag lost | | | | |
| 115|Sf lost |system disturbance indications lost | |K | | |
| 203|St. del |fault data storage deleted |K | | | |
| 301|Netwflt. |system disturbance |K |K | | |
| 302|Fault |fault |K |K | | |
| 501|Dev. Act. |protection (gen.) activation | |KG| |O|
| 511|Dev. TRIP |protection (gen.) general tripping | |K | |O|
| 525|I1 |switched off current I1/In= | |K | | |
| 605|I1= |operational measured value station 1 in % |MV| | | |
| 606|I2= |operational measured value station 2 in % |MV| | | |
| 608|ID= |operational measured value diff current in % |MV| | | |
| 609|IS= |operational measured value rod current in % |MV| | | |
| 655|I1= |operational measured value station 1 in A |MV| | | |
| 656|I2= |operational measured value station 2 in A |MV| | | |
|1157|>LSeinA |>LS auxiliary contact all poles closed |KG| |I|O|
|1174|LS–test |circuit–breaker test running |KG| | |O|
|1185|TST TRIP |LS test trip 3–phase |KG| | |O|
|3003|>DIFblk |>blocking DIFF protective function |KG| |I|O|
|3008|>Res.LO |reset the lockout | | |I|O|
|3015|DIF.off |differential protection is switched off |KG| | |O|
|3016|DIF.blk |differential protection blocked |KG| | |O|
|3017|DIF.act |differential protection active |KG| | |O|
|3021|DEL.st |delay for trip by IDIFF> started | |KG| |O|
|3022|DIF.GA |diff. protection general activation | |KG| |O|
|3024|B.DIF S |block. by saturation in the DIFF current | |KG| |O|
|3026|B.DIF H |blocking by harmonics | |KG| |O|
|3027|DIF TRIP |diff. protection tripping stage IDIFF> | |K | |A|
|3028|Trans.sen |transfer trip is sent | |KG| |O|
|3030|B.DIF D |blocking by DIFF current superv. |KG| | |O|
|3031|Lockout |Lockout state of the trip |KG| | |O|
+ +
