SILENT KNIGHT 4821 - Using the Chart (Table 6-3)

Model 4821/4820 Control/Communicator Installation Manual
6-8 150966
Example:
Suppose your profile is called “Normal” and you want to change the name to “Typ Empl”.
1. When the profile editing keys are scrolling, press to move into the profile name.
Your cursor will be positioned under the “l” in “Normal”.
2. Press to erase the “l”.
3. Press to move to the “r” in “Normal”. Press to delete.
4. Continue pressing and as necessary.
When you have finished erasing all the characters, you can enter the characters for Typ Empl
as shown in Table 6-3.
Using the Chart (Table 6-3)
The chart below provides a quick reference for entering characters. The column labeled “1st
digit” is for selecting the set of characters. The column labeled “2nd digit” is for selecting the
actual character.
Example:
To select uppercase A, press .
To select the character
&
for a profile name, press .
To select lowercase
u
, press .
Table 6-3: Entering Characters
2nd digit
0 1 2 3 4 5 6 7 8 9
1st digit
0@ ABCDEFGHI
1J KLMNOPQRS
2T UVWXYZ[ ¥ ]
3` abcdefghi
4j kl mnopqr s
5t uvwxyz{| }
60 123456789
7(blank)!“#$%&‘()
8* +,-./:;^_
9
→←
<=>?
STAT
CLR
STAT CLR
STAT CLR
0
1
7
6
5
1
⇒
⇓
