1.1.1 Compatible Modules
Table 1-1 shows the modules available for use with the 4821/4820. The third column of the
chart shows where to find installation instructions for the module. (See Figure 1-1 for a block
diagram or compatible units.)
Table 1-1: Modules Compatible with the Model 4821/4820
Model Description
See Section (for more
information)
4195 Auxiliary Power Supply Provides an additional 2.5 amps of power and allows
for a second 12-volt, 7.0 AH battery to be added to the
system.
Section 4.12 of this manual.
4815 Serial Zone Expander 128-Zone Serial Expander. Used with SmartSensors.
4815 Installation
section of
this binder (P/N 150909).
4111 SmartSensors Serial sensors for use with the 4815.
4815 Installation
section of
this binder (P/N 150909).
4114 End-of-Line Resistor 1.43K ohm EOL resistor for use with Model 4111
SmartSensor. The 4114 is required for UL installations.
4815 Installation
section of
this binder (P/N 150909).
4181X10 Powerline Interface For connecting X10 modules to the 4880.
(Note: X10 modules are not UL listed for fire and
burglary applications.)
4880 Installation
section of
this binder (P/N 150912).
1
2
4205 Slimline Touchpad
For access control installations. Requires the 4421 Door
Access Module (see note 1 below). Cannot be used with
the 4820 control panel.
Section 3.1 of this manual
1
4300 Classic Wiegand Swipe
Card Reader
26-bit Wiegand type swipe card reader for indoor or
outdoor use. Has fully encapsulated head to withstand
tampering and environmental damage. Compatible with
4301 swipe cards.
Section 3.2.3 of this manual
1
3
4301 Wiegand Acces Card
For use with Model 4300 Card Swipe Reader.
1
4305 Proxima Clip-on Badge
Proximity Card,
1
4306 Proxima
Laminated Vinyl Proximity
Card,
1
4308 Proxima Proximity
Key tag
For use with Model 4330/4340/4350 readers.
1
4330 Proxima Mullion Mount
Proximity Card Reader
Mullion mount type reader, 26- or 34-bit selectable. Section 3.2.4 of this manual
1
4340 Proxima Standard Range
Proximity Card Reader
Standard range reader, 26- or 34-bit selectable. Section 3.2.4 of this manual
1
4350 Proxima Medium Range
Proximity Card Reader
Medium range reader, 26- or 34-bit selectable. Section 3.2.4 of this manual
1
3
4421 Door Access Module
Hardware interface for 26-bit or 34-bit Wiegand type
card readers and for the 4205 Slimline Touchpad.
Section 3.1 of this manual
