Model 4821/4820 Control/Communicator Installation Manual
7-2 150967
7.2 SIA Event Codes
Table 7-2 lists the SIA event codes that the 4821/4820 can send. When an “X” appears in the
“Not supported by 9000” column, it means that the code cannot be received by the current
version of the 9000.
Note: If an unsupported code is sent to the 9000, it is possible that an erroneous message could be printed on the
9000’s on-board printer. Unsupported codes will send correct information through the 9000’s automation
computer port.
Table 7-2 SIA Event Codes
Event Code Transmitted
9000 SIA Upgrade
required
AC Restoral AR
AC Trouble AT
Burglary Alarm BA#
Burglary Bypass BB#
Burglary Alarm Restore BH#
Burglary Trouble Restore BJ#
Burglary Trouble BT#
Burglary Unbypass BU#
Automatic Closing CA
Forced Closing CF#
Close Area CG#
Closing Report CL#
Late to Open CT#
Door Access Denied DD
Door Forced or Door Monitor Alarm DF#
Access Granted DG#
Door Held Open DO#
Door or Door Monitor Alarm Restored DR#
Door Monitor Trouble DT#
Expansion or Modem Restoral ER#
Expansion or Modem Trouble ET#
Fire or Fire Contact Alarm FA#
Fire or Fire Contact Bypassed FB#
Fire or Fire Contact Alarm Restore FH#
Fire or Fire Contact Trouble Restore FJ#
Fire or Fire Contact Trouble FT#
