Programming
150966 6-23
6.3.2.3 Zones Screen
Use this screen to select options for zones. If you are using templates as a way to simplify
zone programming and need information for creating them, see the 5580 Upload-Download
Software Installation and Operation Manual (P/N 150925).
Table 6-7: Zones Screen Options and Descriptions
Option Description Default
Zone number Enter the zone number for this zone. Valid range is 1-999. (Total number of system zones
is 400.)
1 (-16)
Location Enter up to 16 characters to describe the zone. Zone 1-16
Zone type Choose the zone type for this zone. Options are listed in Table 6-8. Burglary
Debounce
Speed
(Zone
Response
Speed)
Select the response speed for the zone. The chart below shows the response speeds avail-
able for the various hardware point zone types. See Section 4.15.6 for more information.
100 msec
**4421 or
Selection Internal or 4825 zones 4860C zones 4815 serial zones
10 msec X not available not available
100 msec X X not available
250 msec not available not available X
1 sec X X X
*10 sec X X X
*Note:Do not select the 10 second response speed for zones that will be programmed as smoke verify.
**Note: The Model 4421 cannot be used with the 4820 control Panel.
Hardware
Point
A hardware point is a number that relates a system zone to its hardware location. Hardware
points are not assigned automatically, but a list of available hardware points displays
automatically on the programming screen. The installer must select a point for each zone
from the list of available hardware points that displays on the programming screen.
Internal
Zone 1-16
