| 43
Waypoints, Routes & Tracks | GN70/MX610/MX612 Operator and Installation Manual
13. Enter description of track, press ENT key, use virtual keypad to enter alphanumeric details.
Use Enter button to exit.
14. Highlight Create Route from track.
15. Highlight the START button then press the ENT key to start the route.
16. Select going forward or reverse, then press the ENT key.
17. At bottom of window, select to delete, show, save or cancel modification.
¼ Note: Show button will display the plot screen
To toggle, press ENT key in the Edit Track window.
To add new Track
1. Press the MENU key.
2. Highlight the Wpt/Rte/trk, then press the ENT key.
3. Press PAGE key, to Tracks tab, see list of tracks.
4. Rotate knob to highlight track line identified as New Track, press ENT key (or for same func-
tion, press MENU key, scroll to New).
5. In New Track window, highlight field, press rotary knob, use virtual keypad to enter name.
6. Press Enter button in keypad when completed.
7. To (remove) display or record track, (un)check the selection.
8. Customize track display, rotate knob to graphic and press rotary knob, from grid select color
of track.
9. Enter description of track, press ENT key, use virtual keypad to enter alphanumeric details.
Use Enter button to exit.
10. At bottom of window, select to save or cancel entry.
11. Press CLR key to exit.
To nd a Track
1. Press the MENU key.
2. Highlight the Wpt/Rte/Trk and press the ENT key.
3. Press PAGE key, to Tracks tab, see list of tracks.
4. Press the MENU key.
5. In submenu, choose Find option, press ENT key.
6. Find from Vessel- Track window, select a track from list below.
7. Press MENU key, scroll to Show option, press ENT key.
The selected track will be displayed in the plot screen.
