74 |
Mounting | GN70/MX610/MX612 Operator and Installation Manual
MX612JB smart junction box unit
340 mm (13.38”)
320 mm (12.60”)
100 mm
(3.94”)
109 mm
(4.29”)
250 mm
(9.94”)
253 mm
(9.84”)
MX612JB JUNCTION BOX
