| 73
Mounting | GN70/MX610/MX612 Operator and Installation Manual
HS80/HS80A/MX575C/MX575D D/GPS compass unit
MX610JB smart junction box unit
211 mm (8.29")
197 mm (7.77")
185 mm (7.27")
60 mm
(2.36")
180 mm
(7.08")
80 mm
(3.15")
48 mm
(1.88")
