Specications | GN70/MX610/MX612 Operator and Installation Manual
Supported data
IEC61162-1/2 (NMEA 0183) interface channels
MX610JB
Channels
MX612JB
Channels
Default name
Default
sentences
Default Baud
rate
1 1 MXJB-NMEA1
GGA, DTM,
ZDA,VTG, HDT
4800
2 2 MXJB-NMEA2***
3 3 MXJB-NMEA 3 - (ANTENNA - GPS I/O)* Off 19.2K**
4 4 MXJB-NMEA4 - (ANTENNA - BEACON Out)* Off 4800
N/A 5 MXJB-NMEA5
GGA, DTM,
ZDA,VTG, HDT
4800
N/A 6 MXJB-NMEA6***
N/A 7 MXJB-NMEA7 Off 19.2K**
N/A 8 MXJB-NMEA8 Off 4800
N/A 9 MXJB-NMEA9
GGA, DTM,
ZDA,VTG, HDT
4800
N/A 10 MXJB-NMEA10***
N/A 11 MXJB-NMEA11 Off 19.2K**
N/A 12 MXJB-NMEA12 Off 4800
* Option for MX521A, MX521B, MX525A and MX575C, MX575D, HS80 and HS80A antenna connection.
** High speed ports, restores to 19,200 after restore or power cycle.
*** Dedicated RTCM data input port. Output is selectable.
GN70/MX61x communications (via NMEA 0183)
Sentence
NMEA 0183
Message Data Type
In Out
ACK √ √ Acknowledge Alarm
ALR √ Set Alarm State
APB √ √ Autopilot Sentence “B”
DPT √ √ Depth
DTM √ √ Datum
GBS √ √ GNS Satellite Fault Detection
GGA √ √ Global Position System Fix data
GLL √ √ Geographic Position - Lat/Lon
GNS √ √ GNSS Fix Data
GRS √ √ GNSS Range Residuals
GSA √ √ GNS DOP's And Active Satellites
GSV √ √ GNSS Satellites in View
HDG √ √ Heading Deviation & Variation
HDT √ √ Heading True
MWV √ Wind Data
RMC √ √ Recommended Minimum Specific GNSS Data
RMB √ √ Recommended Minimum Navigation Information
ROT √ √ Rate Of Turn
RTE √ √ Routes
THS √ √ True Heading
VHW √ √ Water Speed and Heading
VTG √ √ Course and Speed Over Ground
WPL √ √ Waypoints
XTE √ √ Cross Track Error, Measured
ZDA √ √ Time & Date
