Simrad GN70 User Manual

88 |
Specications | GN70/MX610/MX612 Operator and Installation Manual
Specications
Technical specications
¼ Note: For updated technical specifications, compliance and certifications, refer to our website
at www.navico.com/commercial
GN70/MX61x control unit
GN70 MX610/MX612
DISPLAY
Size 5 in. (127 mm)
Resolution (HxW) 480x480
Type 16-bit color TFT
Antifog Bonded LCD
Best viewing direction Any direction
Backlight Cold Cathode Fluorescent Lamp (CCFL)
Waypoints 2000
Routes 100 Routes with a dynamic number of waypoints; up
to 2000 in all routes
Tracks 2000
NETWORKING
CAN bus NMEA 2000 (N2K)
Ethernet (LAN) Yes- used for software update and NMEA 0183/IP
USB Socket No Yes
POWER
Local supply 12/24 VDC +30-10%
Consumption local supply 0.7/0.4 A at 12 VDC 0.4/0.3 A at 24 VDC
“backlight full/off"
NMEA 2000 LEN* (50 mA) 1
INTERFACE External alarm/Active unit output max 100 mA, 4.5 A
short circuit limit
External MOB input, contact current max 8 mA
ENVIRONMENT
Temperature, operation -30°C to +55°C (-22°F to 131°F)
Temperature, storage -25°C to +70°C (-13°F to 158°F)
Protection IPx4
MECHANICAL
Weight 1,2 Kg (2.7 lbs) 1.4 Kg (3.0 lbs.)
Size 230 (W) x 144 (H) x
54 (D) mm
252 (W) x 144 (H) x
54 (D) mm
Mounting Panel (flush) or optional bracket
Material Epoxy coated seawater resistant aluminium back
cover, plastic front bezel
Color Black and grey
Cable inlet 1 Power/alarm, 1 Micro-C, LAN connectors
* LEN - NMEA 2000 Load Equivalent Number. Where 1 LEN draws about 50 mA current
from the N2K network.
