| 87
Wiring | GN70/MX610/MX612 Operator and Installation Manual
HS80/HS80A N2K connection
T
12/24V DC
MX61xJB
Junction Box
12/24V DC
Where:
N2K Backbone
Drop line
NMEA 0183 line
GN70/MX610/MX612
HS80/HS80A
GPS Compass
Ports 4
Port 2
Port 1
T
