Simulator | NSO-II Operator Manual
Simulator
Simulator mode
The simulation feature will let you see how the unit works in a stationary position and
without being connected to echosounder, radar, GPS etc.
You can use the simulator to help you become familiar with your unit before using it out
on the water.
When the simulator is toggled on this is indicated in the lower part
of the display.
Demo mode
In this mode the unit automatically runs through the main features of the product; it
changes pages automatically, adjusts settings, opens menus etc.
If you tap the screen or press a key when demo mode is running, the demonstration will
pause. After a time-out period, demo mode will resume.
Selecting simulator source les
You can select which data les to be used by the
simulator.
A set of source les is included in your system, and you
can import les by using an SD card inserted into the
unit’s card reader on the processor box.
You can also use your own recorded echosounder les
in the simulator.
Advanced simulator settings
The advanced simulator settings allow you to dene how to run the simulator. When the
settings are saved these will be used as default when starting the simulator mode.
GPS source
Selects where the GPS data is generated from.
Speed, Course and Route
Used for manually entered values when GPS source is set
to Simulated course or Simulated route. Otherwise, GPS
data including speed and course comes from the selected
echosounder or radar les.
Set start position
Moves the vessel to current cursor position.
21
See “Recording
echosounder data” on page
58 for information about
how to record sounder les.
