| 15
Basic operation | NSO-II Operator Manual
Pages and panels
Select pages
You access a page group and then select the page to display from the PAGES panel.
Select active panel
In a split screen you have multiple panels, but only one panel can be active at a time.
You will only be able to access the context menu of the active panel. The active panel is
outlined with a red border.
You can switch between active panels by tapping the required panel or pressing the OP40
WIN key.
Menus
Menus are used to operate the system and to adjust settings.
To call up a menu:
• Press the panel button or OP40 MENU key
• Press and hold on active panel
• You select a menu item and toggle on/o menu check boxes by tapping selected item.
• You adjust slide bar values by tapping the item and then dragging your nger on the
slide bar. The value can also be adjusted by turning the OP40 rotary knob.
• Drop-down listings are selected by tapping the item and then the selected value.
Check box Slide bar Drop-down listing
From the OP40 Remote Controller you can also operate a menu by using the rotary knob
to select menu item, and then press the knob to conrm your selection.
By pressing the X key the menu will return to previous menu level, and then exit. You can
also close a menu by tapping the screen outside the menu area.
