BEP CZone | NSO-II Operator Manual
CZone system overview options
Enables you to monitor all on board parameters including tank levels displayed in
graphical, percentage and remaining volume formats.
Shows control options and monitoring information.
Displays visual and audible alarms that can be set for high and low levels.
CZone info panel
When the CZone is installed and congured, an additional CZone dashboard will be
added to the Instrument panels.
Vessel dashboard Navigation dashboard Angler dashboard CZone dashboard
You switch between a panel’s dashboards by tapping the left and right arrow symbols or
by selecting the dashboard from the menu.
Editing the CZone dashboard
You can customize CZone dashboard by changing the data for each of the gauges.
Available editing options will depend on the type of gauge and which data sources are
connected to your system.
CZone AC Main Control Interface (AMCI) and AC Output In-
terface (ACOI) support
AMCI allows you to select which mains power device will supply power to the vessel. ACOI
provides on/o control and power distribution protection for AC devices on the vessel.
AC controls are congurable under Control and Monitor panel.
See “Instrument
panels” on page 70 for
further information.
