Audio | NSO-II Operator Manual
The audio outputs are organized in 3 zones. You can adjust balance, volume and volume
limit settings independently for each zone. Adjustments to the bass and treble settings
will alter all zones. Refer graphics.
Zone 1 Left/Right speakers
Zone 2 Left/Right speakers
Zone 3 Amplier output, Subwoofer output
Master volume control
By default the volume for all speaker zones are adjusted when you adjust the volume on
an NSO-II unit.
You can adjust each speaker zone individually from any NSO-II unit from the SonicHub
Zones dialog. From this dialog you can also dene which zones shall be altered when you
increase/decrease the volume from the control unit.
Operating the audio source
Selecting the audio source
You switch between available audio sources from the audio menu.
¼ Note: The Mic source selects a high voltage level input allowing you to broadcast loud
hailer messages over the audio system.
Adjusting the volume
The volume is adjusted by using the OP40 rotary knob or by tapping the
volume level icon and then dragging your nger on the slide bar.
The volume can also be adjusted by using the menu, and from the master
control dialog as described later in this chapter.
Muting
You toggle muting on/o by pressing the OP40 rotary knob.
