15. Appendices
EN
15. Appendices
Table 7. Selector switch J9
Selector switch J9 Meaning
Closed Lubrication system settings can be changed using the function button.
Open
Lubrication system settings can be changed using rotary switches.
Does not apply to ProFlex systems.
Table 6. Selector switches J4E, Multilube pump control selection
Selector switch J4E Meaning
Closed Multilube pump control is active.
Open Multilube pump control is inactive.
When J9 is closed, only the function button
can be used for setting lubrication param-
eters. Circuit board rotary switches SW1
and SW2 must be set to zero (0). If not, all
indicators in the control panel will flash in
succession and the lubrication program will
not start. The indicators will also flash in
succession in other cases where the jumper
switches have been incorrectly set and the
lubrication program fails to start.
