15. Appendices
EN
15. Appendices
6.1
Changing lubrication parameter set-
tings using the function button
The function button allows users to set the
lubrication interval, maximum pressurisa
-
tion time and, in progressive systems, the
required number of lubrication pulses.
6.1.1
Setting the lubrication cycle
Lubrication cycle refers to the time in which
all lubrication points get lubricated.
Press the function button for approximately
5 seconds. Once indicator 1 starts flashing
rapidly, release the function button.
The control centre is now in lubrication cycle
setting mode.
Indicator P indicates the current value of
the lubrication cycle. The indicator will flash
1–10 times. After this, there will be a 2 sec
-
ond pause and indicator P will again flash
1–10 times. The current set value of the lu
-
brication cycle can be determined using the
following table.
To increase the lubrication cycle setting by
one increment, briefly press the function
button. When the highest setting is reached,
the setting cycle starts from the beginning.
To exit the lubrication cycle setting and save
it in the circuit board memory, hold the func-
tion button for approximately 5 seconds,
after which all three indicators will light up.
Table 8. Lubrication cycle settings
Flashes
Lubrication cycle
(min)
1 5
2 10
3 15
4 20
5 30
6 45
7 60
8 80
9 100
10 120
